Product Instructions
CAUTION
• The spindle rotates when the system is switched on and the tool is calibrat-
ing.
After successful initialization, the system is ready for use.
Controller
NOTICE
• PSets are stored in the controller. The controller is initially programmed
with a number of default PSets that will work on any tool type.
• If a PSet is changed in any way, it will be assigned to the connected tool
type. If a tool of a different type is connected, this PSet can not be used.
Another PSet must then be choosen, or the PSet must be reconfigured,
either in Tools Talk MT, or using Auto-set.
Buttons and indicator
Auto-set
1. Press either the UP or the DOWN button
2. Select Autoset in the menu.
3. Press OK.
4. If required, enter the password. Use the OK button to select a position and
the UP or the DOWN buttons to select the number.
5. Set the required tightening torque. Use the UP or the DOWN buttons to set
the torque.
6. Press OK.
12
EN
UP button:
DOWN button:
OK button:
STATUS indicator:
© Atlas Copco Industrial Technique AB - 9836 629400 00
• Enter the system menu
• Move the selection up
• Enter the system menu
• Move the selection down
• Switch the controller on and off
• Confirm the selection
• Green - Tightening OK
• Blue - Batch finished
• Red - Error
MT Focus 400
