Atlas Copco MT Focus 400 Produktanweisungen Seite 13

MT Focus 400
7. Check that the correct PSet is shown. If so, select yes and press OK.
If not, return by selecting no and pressing OK.
8. Perform three tightenings.
NOTICE
• Each tightening should be done using a new joint.
9. If tightenings are not successful, repeat the tightening. if all tightenings are
successful, Auto-set done is shown.
10. If the speed is to be changed, press the DOWN button and use the UP or
the DOWN buttons to set the speed. Press OK to continue.
11. If the min. angle is to be changed, use the UP or the DOWN buttons to set
the min. angle. Press OK to continue.
12. If max. angle is to be changed, use the UP or the DOWN buttons to set the
max. angle. Press OK to continue.
13. If the trigger torque for angle counting is to be changed, use the UP or the
DOWN buttons to set the trigger torque for angle counting. Press OK to
continue.
14. In order to revise the settings, repeat steps 10-13.
15. Press OK to finish.
Select program set (PSet)
1. Press either the UP or the DOWN button
2. Select Select PSet in the menu.
3. Press OK.
4. If required, enter the password. Use the OK button to select a position and
the UP or the DOWN buttons to select the number.
5. Select the required program set.
6. Press OK.
Batch control
To set the batch size:
1. Press either the UP or the DOWN button
2. Select Batch control in the menu.
3. Press OK.
4. Select Set batch size in the menu.
5. Press OK.
EN
© Atlas Copco Industrial Technique AB - 9836 629400 00
Product Instructions
13
