Setting The Mac Id; Setting The Baud Rate - Fronius AB DeviceNet Enterprise Bedienungsanleitung

Setting the Mac
ID
TCP/IP configuration switch
Mac ID
0
1
2
3
...
62
63
Setting the baud
rate
TCP/IP configuration switch
44
sw. 3 (MSB) sw. 4
OFF OFF
OFF OFF
OFF OFF
OFF OFF
... ...
ON ON
ON ON
The Mac ID is set using Dip switches 3
- 8 on the TCP/IP configuration switch.
sw. = DIP switch
sw. 5 sw. 6 sw. 7
OFF OFF OFF
OFF OFF OFF
OFF OFF ON
OFF OFF ON
... ... ...
ON ON ON
ON ON ON
The baud rate is set using Dip switches
1 - 2 on the TCP/IP configuration
switch.
sw. = DIP switch
Baud rate
125 kBit/s
250 kBit/s
500 kBit/s
reserviert
sw. 8 (LSB)
OFF
ON
OFF
ON
...
OFF
ON
sw. 1 sw. 2
OFF OFF
OFF ON
ON OFF
ON ON
