Data transfer properties and technical data
Data transmissi-
Network topology
on properties
Medium
Max. number of nodes
Max. bus length, depends on
the baud rate:
Bus connection
Operating modes
Process data width
Process data format
Safety features
If there is no data transmission, all inputs and outputs are reset and the power
source goes into „Stop". Once data transmission has been re-established, the fol-
lowing signals resume the process:
-
-
AB DeviceNet
Power supply
Enterprise tech-
Current input
nical data
Position on the rear of the power
sources:
Protection
Configuration interface
EDS file - Elec-
An EDS file is assigned to every node in a DeviceNet network. The EDS file con-
tronic Data
tains all the information about the node. It is required for the network configura-
Sheet
tion and can be downloaded from the following website:
http://www.anybus.de/products/devicenet/Techn. Dokumentation/Configuration
file
50
"Robot ready" signal
„Source error reset" signal
bus terminators at both ends (121 Ohm),
Screened 2x2 twisted-pair cable,
100 m at 500 kBit/s
250 m at 250 kBit/s
500 m at 125 kBit/s
Open Style connector, 5-pin
Bit Strobe, Polling, Cycling,
Change of State (COS)
104 bits (standard configuration)
24 V DC +/- 10% internal
TPS 3200 / 4000 / 5000
Via field bus configuration module
Linear bus,
spur lines possible
must be screen
64
Intel
400 mA (typical)
TS 4000 / 5000
IP23
