6.20 Object 1F93h: NMT_EPLNodeID_REC
The object stores the devices's EPL Node-ID.
Index
Name
Data type
Sub-Index
Description
Access
PDO mapping
Default value
Value range
Sub-Index
Description
Category
Data type
Access
PDO mapping
Default value
Value range
Sub-Index
Description
Category
Data type
Access
PDO mapping
Default value
Value range
Printed in the Federal Republic of Germany
06/26/2017
0x1F93
NMT_EPLNodeID_REC
NMT_EPLNodeID_TYPE
000
Number of entries
CONST
no
0x02
0x02...0x03
001
NodeID_U8,
indicates the Node-ID, adjusted by means of the hardware switches
Mandatory
UNSIGNED8
ro
no
0x1
0x01...0xFE
002
NodeIDByHW_BOOL,
indicates if the EPL Node-ID can be adjusted by means of
hardware or software
Mandatory
BOOLEAN
ro
no
0x1
0 = Software adjustment, 1 = Hardware adjustment
TR - ECE - BA - DGB - 0071 - 05
Object type RECORD
Category Mandatory
