Installation / Preparation for Commissioning

4.2 Connection

X1 POWERLINK-IN / X2 POWERLINK-OUT
Pin 1
Pin 2
Pin 3
Pin 4
X3 Supply
Pin 1
Pin 2
Pin 3
Pin 4
Shielded twisted pair cables must be used for the supply!
The shielding is to be connected with large surface on the mating connector
housing!
Order data for Ethernet flange socket M12x1-4 pin D-coded
Manufacturer
Binder
Phoenix Contact
Phoenix Contact
Harting
1)
for service purposes, e.g. software update
 TR-Electronic GmbH 2008, All Rights Reserved
Page 128 of 187
TxD+, transmitted data +
RxD+, received data +
TxD–, transmitted data –
RxD–, received data –
19 – 27 V DC
1)
TRWinProg+
GND, 0 V
1)
TRWinProg–
Designation
Series 825
SACC-M12MSD-4CON-PG 7-SH (PG 7)
SACC-M12MSD-4CON-PG 9-SH (PG 9)

HARAX M12-L
TR - ECE - BA - DGB - 0071 - 05
Flange socket M12x1-4 pin D-coded
Flange connector M8x1-4 pin
Order no.:
99-3729-810-04
15 21 25 8
15 21 26 1
21 03 281 1405
