Instructions for mounting / schematic

4.3 Integrated claw coupling

4.3.1 Mounting with coupling

Measuring systems with integrated coupling are standalone devices and cannot be
produced by remodelling of a standard device with shaft.
Features:
 Short construction length (integrated coupling in the measuring system shaft)
 Simple and fast mounting / dismounting
 Radial and axial tolerance to the customer shaft.
 Only few components necessary
