9.4 Error Register, Object 0x1001

Bit Failure
0 Bit 0 = 1
Table 20: Error signaling in the Error Register 0x1001

9.5 Miscellaneous faults

Fault
Position skips
of the measuring
system
Table 21: Miscellaneous faults
Printed in the Federal Republic of Germany
06/26/2017
Cause
Device internal fault occurred.
Either the node is in state "Error
Condition" (NMT_CT11) or in
"Internal Communication Error"
(NMT_GT6) state.
Cause Solution
Vibrations, impacts and shocks, e.g. on presses, are
dampened with "shock modules". If the error recurs
Strong vibrations
despite these measures, the measuring system must be
replaced.
Perhaps isolated flanges and couplings made of plastic
help against electrical faults, as well as cables with twisted
Electrical faults pair wires for data and supply. The shielding and line
EMC routing must be executed in accordance with the
Equipment Mounting Directives for the respective field bus
system.
Extreme axial and
Couplings prevent mechanical stress on the shaft. If the
radial load on the
error still occurs despite these measures, the measuring
shaft may result in a
system must be replaced.
scanning defect.
TR - ECE - BA - DGB - 0071 - 05
Remedie
In order to locate the error, the reported Error
code in the StatusResponse frame must be
evaluated, see Error Codes on page 186.
Optionally the threshold must be adjusted in the
corresponding objects.
