Pinbelegung der Feldbusse
10.9.3 FlexRay-Bus (DSUB-9)
imc Standard Ausführung mit einem DSUB-9 zwei Kanälen pro DSUB:
DSUB-Pin
1
2
3
4
5
6
7
8
9
Optionale Ausführung mit zwei DSUB-9: mit je einem Kanal pro DSUB (CON1 und CON2)
DSUB-Pin
CON1
1
n.c.
2
BM Kanal A (negativer Bus-Anschluss Kanal A)
3
GND
4
n.c.
5
GND
6
n.c.
7
BP Kanal A (positiver Bus-Anschluss Kanal A)
8
n.c.
9
n.c.
Zu den
technischen Daten
10.9.4 XCPoE (RJ45)
Standard Ethernet 1x RJ45.
Zu den
technischen Daten
© 2023 imc Test & Measurement GmbH
Signal
n.c.
BM Kanal A
GND
BM Kanal B
GND
n.c.
BP Kanal A
BP Kanal B
n.c.
und der
Verkabelung
438
und der
Verkabelung
440
negativer Bus-Anschluss Kanal A
FlexRay Ground
negativer Bus-Anschluss Kanal B
FlexRay Ground
positiver Bus-Anschluss Kanal A
positiver Bus-Anschluss Kanal B
CON2
n.c.
BM Kanal B (negativer Bus-Anschluss Kanal B)
GND
n.c.
GND
n.c.
BP Kanal B (positiver Bus-Anschluss Kanal B)
n.c.
n.c.
der FlexRay-Bus Schnittstelle.
99
der XCPoE Schnittstelle.
99
imc CRONOS Systemfamilie - Handbuch, Edition 11 - 06.06.2023
Beschreibung
Kapitel 10
Seite 482
