Appendix
7.1
Copyright
This document is protected by copyright. All derived rights are reserved, especially those of
translation, re-printing, use of figures, broadcast, reproduction by photo-mechanical or similar
means and recording in data processing systems, either partial or total.
Subject to technical changes without notice.
7.2
Terminology/Glossary
Term
Cross table
Taper mandrel
Workpiece
Draw-in rod
Drill chuck
Collet chuck
Drilling and milling head
Spindle sleeve
Milling spindle
Drilling table
Taper mandrel
Spindle sleeve lever
Quick action - drill chuck
Workpiece
Tool
7.3
Change information operating manual
Chapter
EC declaration
4
2 + 4 + DRO5 + wiring
diagram
EC declaration
1 + 5
MP4PV electrical parts
3
EN
MB4P ǀ MB4PV
114
Explanation
Bearing surface, clamping surface for the workpiece with X- and Y-axis
travel
Cone of the drill or of the drill chuck
piece to be milled, drilled or machined.
Threaded rod to fix the taper mandrel in the spindle sleeve.
Drill bit adapter
Holder for end mill
Upper part of the drilling-milling machine
Hollow shaft in which the milling spindle turns.
Shaft activated by the motor
Supporting surface, clamping surface
Cone of the drill or of the drill chuck
Manual operation for the drill feed
Drill chuck can be fixed by hand.
Piece to be drilled or machined.
Milling cutter, drill bit, etc.
Short summary
changed standard
Switching the machine on - expanded Information
Machine type MB4PV integrated
New EMC Directive and Low Voltage Directive
Advanced information on inspection schedules
SKBD200150 1.5KW, new M100-022 00075 1.5KW
Notes on the circuit breaker
Translation of original instructions
new version number
1.0.1
1.0.2
1.1.0
1.1.0
1.1.0
1.1.1
1.1.2
Version 1.1.8 - 2021-7-29
