Specifications
9.1 Versions and ordering numbers
Code Measurement
range
0050 50N
0100 100N
0200 200N
00K5 0.5kN
01k0 1kN
02k0 2kN
05k0 5kN
10k0 10kN
20k0 20kN
50k0 50kN
K-U9C- 05k0-
All cable lengths can be combined with all plugs.
Information
TEDS can only be ordered in conjunction with a plug option. It is not possible
to combine TEDS and free cable ends.
Versions with inline amplifiers (VA1 and VA2) can only be combined with cable
lengths 1.5 m and 2 m; TEDS is not available for these measurement chains.
36
Ordering number
1­U9C/50N
1­U9C/100N
1­U9C/200N
1­U9C/0.5KN
1­U9C/1KN
1­U9C/2kN
1­U9C/5kN
1­U9C/10kN
1­U9C/20KN
1­U9C/50KN
Cable Electrical connection
length
1.5 m
01m5
3 m 15-pin Sub-D connector
03m0
5 m Male connector MS3106PEMV
05m0
6 m 15-pin Sub-D connector
06m0
7 m With inline amplifier 0...10 V
07m0
12 m With inline amplifier 4...20 mA
12m0
12m0-
A03815_03_YI0_01 HBM: public
The ordering numbers shown in gray are pre­
ferred types. They can be delivered rapidly.
All force transducers with 1.5 m cable, open ends
and without TEDS.
The ordering number for the preferred types is
1‐U9C...
The ordering number for customer-specific
designs is K‐U9C‐...
The ordering number example
K-U9C-05k0-12m0-F-T shown here refers to a
U9C, 5 kN nominal (rated) force with 12 m cable,
15-pin Sub-D connector and TEDS.
Free ends
Y
F
N
Q
VA1
VA2
F-
Transducer
identification
With TEDS chip
T
Without TEDS chip
S
T
U9C
