Fig. 8.5 U9C dimensions when using one or two knuckle eyes.
Nominal (rated)
force
50 ... 20 N
0.5 ... 1 kN
2 ... 20 kN
50 kN
Tab. 8.1 Mounting dimensions of the U9C when using knuckle eyes
U9C
a a
min
55
56
79
116
A03815_03_YI0_01 HBM: public
b
max min
[mm]
59 82
61 83
82 122
116 180
Dimensions
b
max
86
88
125
180
