How Supplied
• The device is supplied sterile in single use, double-peel packages in a variety of sizes�
Figure 1: Expansion Example*
* Drawing shows a 2:1 expansion ratio example that is not to scale and not representative of the
entire product line�
Symbols Used on Labeling
Symbols Title
Device Depiction
European
Conformity
0344
Catalogue number
Operators
manual; operating
instructions
Sterilized using
ethylene oxide
Manufacturer
+30°C
+86°F
Temperature limit
+15°C
+59°F
Explanatory Text
Represents relative device shape and pattern� For
meshed patterns, the symbol represents that the
device can be expanded to approximately twice
its length in the direction perpendicular to the
fenestrations
To indicate that the device complies with the
requirement of directive 93/42/EEC�
To identify the manufacturer's catalogue
number�
To identify the location where the operation's
manual is stored� To indicate that the operating
instructions should be considered when
operating the device�
To indicate that the device is provided sterile
and has been sterilized using ethylene oxide�
To identify the manufacturer of a product�
To indicate the maximum and minimum
temperature limits at which the item shall be
stored, transported or used�
5
Reference
Standard
Number
N/A N/A
European
Directive 93/42/ N/A
EEC
2493
1641
ISO 7000,
Graphical
2501
symbols for use
on equipment
3082
0632
