6.3 Display of the current charge level
Power supply and battery charger operating states
During the charging process, the current battery charge level (Status signals) is indicated by the
LEDs on the battery charger lighting up in sequence (see fig. 3, items 2-5).
Querying battery charge level on prosthetic system
The battery charge level can be queried at any time.
1) With the prosthetic system switched on, press the charging receptacle button and hold for
less than one second.
2) The LED display on the charging receptacle provides information on the current battery
charge level (Status signals).
6.4 Safety Shutoff
The purpose of the Axon-Bus prosthetic system safety shutoff is to protect the battery; it is
triggered in case of:
• Excessively high or low temperature
• Overvoltage or undervoltage
• Short circuit
After a short circuit, the charging plug must be plugged into the charging receptacle and then
unplugged in order for the electronics to be activated.
7 Use
7.1 Switching the Axon-Bus prosthesis system on and off
INFORMATION
Switching off the Axon-Bus prosthetic system during extended passive pauses (e.g. air or rail
travel, visit to a theatre or cinema, etc.) will make the battery last longer before requiring a
recharge. Only the entire Axon-Bus prosthetic system with all connected components can be
switched off. Individual Axon-Bus components cannot be switched off separately.
7.2 Opening the Axon-Bus gripping component in an emergency
The product is switched on and off by pressing the button in the char­
ging receptacle on the outside of the socket.
This safety function allows the Axon-Bus gripping component to be
opened regardless of the control signals present.
1) With the Axon-Bus prosthetic system switched on, press the char­
ging receptacle button and hold for approximately three seconds
until the Axon-Bus gripping component begins to open.
→ A pulsating beep sounds as it opens.
2) Releasing the button immediately stops the process of opening
the Axon-Bus gripping component and turns the entire Axon-Bus
prosthetic system off.
