5 Scope of Delivery and Accessories
Scope of Delivery
The product is delivered preinstalled. The scope of delivery includes:
•
1 pc. Axon-Bus transcarpal prosthetic system
•
1 pc. 757L500 AxonCharge Integral
•
1 pc. 646D903 instructions for use (user)
•
1 pc. prosthesis passport
•
1 pc. card holder for prosthesis passport
•
1 pc. cosmetic case for battery charger and power supply
Accessories
The following components are not included in the scope of delivery and may be ordered separ
ately:
•
4X500 AxonCharge Mobile
•
757S500=* AxonCharge adapter
•
8S501=* AxonSkin Natural for men (different skin colours)
•
8S502=* AxonSkin Natural for women (different skin colours)
•
8S500=* AxonSkin Visual (sheer, translucent)
•
8S511=* AxonSkin Silicone for men (different skin colours)
•
8S512=* AxonSkin Silicone for women (different skin colours)
6 Charging the battery
The following points must be observed when charging the battery:
•
The capacity of a fully charged battery is sufficient for one full day.
•
We recommend charging the product every day when used on a daily basis.
•
When used daily, the complete charging unit (power supply – battery charger) may remain
plugged into the wall socket.
•
The battery should be charged for at least 3 hours prior to initial use.
•
Use the 757L500 battery charger to charge the battery.
6.1 Connecting the power supply and battery charger
1) Slide the country-specific plug adapter onto the power supply until it locks into place (see
fig. 1).
2) Connect the round plug of the power supply to the receptacle on the battery charger so that
the plug locks into place (see fig. 2).
INFORMATION: Ensure correct polarity (guide lug). Do not use force when connecting
the cable plug to the battery charger.
3) Plug the power supply unit into the wall socket.
6.2 Connect battery charger to the product
24
1) Connect the charging plug to the charging receptacle of the
product.
→ The correct connection of the battery charger to the product is
indicated by feedback (see Page 32).
2) The charging process starts.
→ The Axon-Bus prosthetic system is switched off automatically.
3) Disconnect the product after the charging process is complete.
