Battery charger
12.2.3 Status signals
Battery charger is connected
Battery charger
Battery charge level
Charging Event
receptacle
Battery is fully charged
Battery charge level is 100%
Battery charge level is over 50%
Battery charge level is less than 50%
12.3 Glossary
The term "Axon" stands for Adaptive exchange of neuroplacement data. The Axon-Bus is an
Ottobock innovation for the field of exoprosthetics: a data transmission system, derived from
safety-related bus systems in the aviation and automobile industries. For the user this means
enhanced safety and reliability because of a considerably reduced sensitivity to electromagnetic
interference in comparison with conventional systems.
32
Explanation/correction
Charger is overheated or overcooled
• Disconnect charging plug and allow charger to cool
down/warm up.
Battery charger or power supply unit is defective
• Consult prosthetist
Explanation
Power supply and battery charger operational
Battery is charging
Battery is charging, battery 25% charged
Battery is charging, battery 50% charged
Battery is charging, battery 75% charged
Battery is fully charged, battery 100% charged
