Beckhoff EL34x3 serie Dokumentation Seite 169

Index 1A00 TxPDO-Map Ch.1
Index (hex) Name
1A00:0 TxPDO-Map Ch.1
1A00:01 SubIndex 001
1A00:02 SubIndex 002
1A00:03 SubIndex 003
1A00:04 SubIndex 004
1A00:05 SubIndex 005
1A00:06 SubIndex 006
1A00:07 SubIndex 007
1A00:08 SubIndex 008
1A00:09 SubIndex 009
1A00:0A SubIndex 010
1A00:0B SubIndex 011
1A00:0C SubIndex 012
1A00:0D SubIndex 013
1A00:0E SubIndex 014
1A00:0F SubIndex 015
1A00:10 SubIndex 016
EL34x3
Bedeutung
PDO Mapping der TxPDO 1
1. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x01 (Undervoltage))
2. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x02 (Overvoltage))
3. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x03 (Overcurrent))
4. PDO Mapping entry (Align)
5. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x05 (Phase sequence cw))
6. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x06 (Phase sequence ccw))
7. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x7 (Missing zero crossing))
8. PDO Mapping entry (Align)
9. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x0F (TxPDO State))
10. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x10 (TxPDO Toggle))
11. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x11 (Current))
12. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x12 (Voltage))
13. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x13 (Active power))
14. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x14 (Index))
15. PDO Mapping entry (Align)
16. PDO Mapping entry (object 0x6000 (PM Inputs Ch.1),
entry 0x1D (VariantValue))
Version: 4.5
Inbetriebnahme
Datentyp Flags Default
UINT8 RO >16<
UINT32 RW 0x6000:01, 1
UINT32 RW 0x6000:02, 1
UINT32 RW 0x6000:03, 1
UINT32 RW 0x0000:00, 1
UINT32 RW 0x6000:05, 1
UINT32 RW 0x6000:06, 1
UINT32 RW 0x6000:07, 1
UINT32 RW 0x0000:00, 7
UINT32 RW 0x6000:0F, 1
UINT32 RW 0x6000:10, 1
UINT32 RW 0x6000:11, 32
UINT32 RW 0x6000:12, 32
UINT32 RW 0x6000:13, 32
UINT32 RW 0x6000:14, 8
UINT32 RW 0x0000:00, 8
UINT32 RW 0x6000:1D,
32
