Installation and Mounting
A measuring wire
under tension
where operators are
standing can lead to
injuries.
> Danger of dam-
age to wire and
sensor.
Do not twist the
measuring wire.
Fig. 11 Dimensional drawing WDS- ... - P96 - CO/PB, dimensions in mm (inches), not to scale
Dimensions in mm (inches)
wireSENSOR, WDS P60/P96/P115
B
A
70 13
(2.75)
(.51)
96
(3.78)
Model
WDS-2000-P96
WDS - P96 - CA - P
WDS - P96 -SR - U/I
WDS-2500-P96 41.4 (1.36) 76.4 (3.00)
WDS - P96 - HTL/TTL
WDS-2000-P96
WDS - P96 - SSI
WDS-3000-P96 41.4 (1.63) 76.4 (3.00)
WDS - P96 - CO/PB
10
(.39)
ø13
(.51 dia)
13
(.51)
56 4x M6
(2.20)
171 2x Slot nut
(6.73)
2x Fixation screw M4
A
32 (1.26) 67 (2.64)
26 (1.02)
36
(1.42)
B
61 (2.40)
