Installation and Mounting
A measuring wire
under tension
where operators are
standing can lead to
injuries.
> Danger of dam-
age to wire and
sensor.
Do not twist the
measuring wire.
Fig. 6 Dimensional drawing WDS- ... - P60 - CAN/PB, dimensions in mm (inches), not to scale
wireSENSOR, WDS P60/P96/P115
MR (mm)
1000
(39.97)
1500
(59.05)
A
38.6 10.7
(1.52)
(.42)
60
(2.36)
81
(3.19)
A (mm)
16.15
(.63)
24.2
(.95)
21.3 40
(1.57)
(.84)
129
(5.08)
10
(.39)
