Functional Principle, Technical Data
Models with potentiometric output WDS - .... - Pxx - CR - P
Electrical data
Supply voltage:
Resistance:
Viper current:
Temperature coefficient:
Sensitivity:
Electrical connection:
i
Models with voltage output WDS - .... - Pxx - SR - U
Electrical data
Supply voltage:
Current consumption:
Output voltage:
Output current:
Load impedance:
Output noise:
Temperature coefficient:
Adjustment ranges
Zero:
Sensitivity:
Electromagnetic
compatibility (EMC):
wireSENSOR, WDS P60/P96/P115
max. 32 VDC at 1 kOhm / max. 1 W
1 kOhm ±10 % (potentiometer)
£ 3 mA
±0.0025 % FSO/K (±0.0014 % FSO/°F)
depends on measuring range, individually reported on product label
Integral cable, radial, 3 wire, 1 m long
Note the slight power dissipation of the potentiometer above +40 °C (+104 °F)! (-0.15 W/10 K)
14 to 27 VDC non stabilized
30 mA max.
0 to 10 VDC (Options: 0 - 5 / ±5 V)
2 mA max.
> 5 kOhm
0.5 mV
±0.005 % FSO/K (±0.0028 % FSO/°F)
±20 % FSO
±20 %
acc. DIN EN 61326-1: 2006-10 and DIN EN 61326-2-3: 2007-05
eff
