MICRO-EPSILON wireSENSOR WDS series Betriebsanleitung Seite 71

Installation and Mounting
Mounting grooves for nut
A measuring wire
under tension
where operators are
standing can lead to
injuries.
> Danger of dam-
Fig. 2 Dimensional drawing WDS- ... - P60 - CR - P , dimensions in mm (inches), not to scale
age to wire and
sensor.
Mounting grooves for nut
Do not twist the
measuring wire.
Fig. 3 Dimensional drawing WDS- ... - P60 - SR - U/I, dimensions in mm (inches), not to scale
wireSENSOR, WDS P60/P96/P115
A
M4 DIN 934 or
bolt M4 DIN 931
1
7
(.28)
38.6
1) max. drive
(1.52)
depth
60
(2.36)
A
M4 DIN 934 or
bolt M4 DIN 931
1
7
(.28)
63 38.6 1) max. drive
(2.48) (1.52)
depth
60
(2.36)
MR (mm) A (mm)
100/300/500/1000 16.15 (.64)
150/750/1500 24.2 (.95)
Cable bending:
R > 15 (.59), one time
R > 50 (1.97), alternating
40
76.5
(3.01)
MR (mm) A (mm)
100/300/500/1000 16.15 (.64)
150/750/1500 24.2 (.95)
Cover bolt for Gain
and Zero pot.
40
95
(3.74)
10
(.39)
(1.57)
10
(.39)
(1.57)
