Error messages

The error numbers are not displayed for units with standard controllers: With the ECoolPLANT software error
numbers can be read on the computer.
 The blinking of the red LED light on the controller circuit board is not a fault indicator or error message. The red
LED light indicates that voltage is supplied to the cooling unit.
Error
Fault
no.
• LED:
Er00
• Compressor:
• Evaporator fan
(internal):
• Condenser fan
(external):
• Heater (external):
• Fault signal contact:
• LED:
Er01
• Compressor:
• Evaporator fan
(internal):
• Condenser fan
(external):
• Heater (external):
Fault signal contact:
• LED:
Er04
• Compressor:
• Evaporator fan
(internal):
• Condenser fan
(external):
• Heater (external):
Fault signal contact:
• LED:
Er05
• Compressor:
• Evaporator fan
(internal):
• Condenser fan
(external):
• External heating:
Fault signal contact:
Operating Manual DTS and DTI 6801 Multi-Controller (MC) 086100008 © Pfannenberg GmbH
Unit activity Possible causes
 Door contact:
Blinking
 The door contact loop has
OFF
been interrupted.
OFF
OFF
OFF
Closed
 Pressostat tripped:
Blinking
 Excessively high pressure
OFF
has built up in the
ON
refrigerant circuit. The
cooling unit cannot
ON
dissipate the heat from the
OFF
refrigerant circuit.
Open
 Phase sequence / phase
Blinking
OFF
loss:
 Failure of at least one
OFF
phase or phase sequence
is incorrect (only with
OFF
alternating current units
OFF
with rotating piston
Open
compressors).
 Sensor 1 (TS1) defective.  Replace Sensor 1 or the
Blinking
ON
ON
ON
OFF
Open
Corrective measures
 Close door.
 Connect door contact
switch.
 Bypass door contact.
 Check wiring.
 Allow the unit to cool
down.
 Clean the heat
exchanger fins
(internal/external).
 Check condenser fan
(external) for function.
 Check the field of
rotation - (clockwise
rotation is required).
 All phases must carry
rated operational
voltage.
controller circuit board
according to the unit
type.
 Replace controller circuit
board if the sensor is
soldered in place.
Page 31 / 43
