look P24 Bedienungsanleitung Seite 31

IMPORTANT PRECAUTION REGARDLESS OF
THE ASSEMBLY
It is important, after 3 assemblies/disassemblies,
to reapply threadlocker to the threads of the
M3x5mm screws using a standard threadlocker
such as LOCTITE 243 TM. Do not grease them
during assembly.
USE OF A TRANSPONDER
For use in competition, it is necessary to install a
transponder. The fork of the LOOK P24 allows it
to be placed on the left dropout, secured with a
3.5mm maximum diameter clamp through the two
holes in the dropout.
INSTALLATION OF THE HANDLEBAR ON THE STEM
The handlebars used on the LOOK P24 are
specific and optimized to assemble only
with the supplied stem. It is possible to place
spacers between the stem and the handlebar
to adjust the stack height and adapt the LOOK
P24 to your position.
The 3 types of handlebars are mounted using
the same procedure described below.
Different available spacers:
Selection of M6 titanium FHC assembly screws
according to the chosen spacer size:
Size spacer Screw size to be used
Aucun spacer M6x25mm
10 M6x35mm
20 M6x45mm
30 M6x55mm
40 M6x65mm
50 M6x75mm
Qty
4
4
4
4
4
4
