3.1 Supplied accessories
Storage box
3.2 Required tools
Air hose
Used to connect an external compressed
air supply.
3.3 Specifications
NOTICE!
» The specifications and constructions outlined in this manual were accurate
at the time of publication. There is a possibility of changes being made to the
specifications and constructions without prior notice or obligations due to
continuous improvements.
Model
Rated power
Spindle speed
Maximum compressed air supply
Air consumption rate
Lubrication oil flow rate
Lubrication oil capacity
Maximum working distance in radius
Tapping range
Maximum tapping diameter
Degree of protection
Number of tap adapters included
Operating temperature
Storage temperature
Weight
8
Quick-connect tap adapters
M3, M4, M5-6, M8, M10, M12, M14, M16
Torque adjustment tool
M3 hex key
Used to loosen or tighten the bolt on the
lubrication port.
H134111
220 V 50 Hz 600 W
312 min
-1
6 to 8 bar
600 to1000 L/min
30 to 60 ml/min
500 ml
110 cm
M3 to M16
Ø16 mm
IP54
8
-10 °C to +70 °C
-10 °C to +70 °C
25 kg
M10 bolts, ×4
M4 hex key
Used to loosen or tighten the fixing bolt
on the height adjustment collar.
3.4 Vibration and noise emission declaration
NOTICE!
» The declared vibration total value(s) and the declared noise emission value(s)
have been measured in accordance with a standard test method given in EN 62841
and may be used for comparing one tool with another. The declared vibration
total value(s) and the declared noise emission value(s) may also be used in a
preliminary assessment of exposure.
CAUTION! Risk of vibration and noise hazards!
» Always wear hearing protection when operating the tool.
» The vibration and noise emissions during actual use of the tool can differ from
the declared values depending on the ways in which the tool is used especially
what kind of workpiece is processed. It is important to identify appropriate safety
measures to protect the operator. These safety measures should be based on an
estimation of exposure levels under the actual conditions of use.
3.4.1 Declared noise emission values
Model
A-weighted emission sound pressure level , L
Uncertainty, K
pA
A-weighted sound power level, L
Uncertainty, K
WA
C-weighted peak emission sound pressure level, L
Uncertainty, K
pC ,peak
3.4.2 Declared vibration emission values
Model
Vibration emission value a
h
Uncertainty K
Power cord
M8 hex key
Used to secure the support base.
H134111
59 dB (A)
pAww
5 dB (A)
62 dB (A)
WA
5 dB (A)
65 dB (A)
pC, peak
5 dB (A)
H134111
6.5 m/s
1.5 m/s
2
2
