6. Shift the inductive sensor to the lower position.
7. Open the Advanced Menu, go to Semi Automatic Bed Leveling Helper and
select Start Procedure. (Fig. 5-1)
The extruders will move to the first calibration point. Follow the lights code to
adjust the height of the bed in that point. See following table:
The bed is well leveled, move to the next point.
Turn the screw counter-clockwise until both green lights are on.
Turn the screw clockwise until both green lights are on.
8. When finished, click on Next Point and repeat the process for each point.
9. Normally you will have to repeat all six points (Fig. 5.3) two or three times until
you get a precise calibration.
10. Shift the inductive sensor back to the higher position.
Fig. 5-1: Advanced Menu
Fig. 5-2: Semi Automatic Bed Leveling
2
0
4
5
MP5
Fig. 5-3: Leveling Points
Installation and commissioning
5.
1
3
=EFS+HB-PE9
21
