Fig. 3-3: BigRep STUDIO G2 without housing
Fig. 3-2: BigRep STUDIO G2 Overview Backside
Construction and Function
3.
Exhaust air tube with fan
Emergency stop button
Maintenance panel
Spool storage space
Air ventilation holes
Main switch
Electrical cabinet
Temperature Controllers
Main plug
Filament guides (2 pcs)
Y-guide rail
X-guide rails (2 pcs)
Z-lead spindels (4 pcs)
Z-guide shafts (2 pcs)
Print bed with Kapton tape
Dual Extruder
Portal
(unit that moves up and down)
