Adjusting device
The laser welding head is fitted with an adjusting device that enables precise positioning
on the laser weld-
in the x and y coordinate axes.
ing head
Adjusting the x-
axis
80
(1)
(2)
(2)
x
NOTE! When using a steel inner liner for the welding torch welding potential may
be present on the adjusting device of the laser welding head !
(2)
The adjusting device basically comprises:
(1)
Adjusting screw with pitch
Allen screw
(3 mm),
quarter turn corresponds to an ad-
justment of 0.25 mm
(2)
Scale denoting adjustment range
(1)
y
Undo grub screw (1)
1
(3 mm)
Use the adjusting screw (2) and the 3
2
mm Allen key to adjust the x-axis:
(1)
1 rotation corresponds to 1.0 mm
Once the x-axis has been adjusted, re-
3
tighten the grub screw (1)
