And finally...
100
1 0
(16) (17)
1 2
(18)
(1)
IMPORTANT! When removing and inser-
ting the protective glass drawer, ensure that
it does not become dirty, scratched or da-
maged in any way.
Take protective glass drawer (16) out
8
of the laser optics system
Swivel the air connection (17) back
9
Connect air hose
10
Reinsert the protective glass drawer
11
(16)
Screw in extraction pipe (18)
12
Slot in the spatter guard sheet (1) and
1
push it forwards
1
