Compressed air
diagram
Designation
Laser optics system water cooling connection
(of LaserHybrid interconnecting hosepack)
External wirefeeding hose (Fronius)
LaserHybrid interconnecting hosepack (Fronius)
Hosepack incl. compressed air for Crossjet and radial air flow, water cooling for
laser optics system and media coupling
(4)
(4)
(5)
(2)
(3)
(3)
(2)
Item
Designation
(1)
Compressor supply
(min. 6 bar)
(2)
Crossjet inlet air connection
(3)
Radial air flow branch connection
(4)
Crossjet outlet air
(5)
Extractor
(1)
1000 l/min
69
