23 Specifications
– Protection class: III
– Degree of protection: IP56
– Maximum mowing area:
®
– iMOW 5.0: 1500 m²
®
– iMOW 6.0: 3000 m²
®
– iMOW 7.0: 5000 m²
– Active time 1000 m² (per week)
®
– iMOW 5.0: 50 h
®
– iMOW 6.0: 35 h
®
– iMOW 7.0: 30 h
– Maximum length of the perimeter wire: 850 m
– Maximum gradient: 40%
®
Bluetooth
– Data connection: Bluetooth
device must be compatible with Bluetooth
Low Energy 5.0 and support Generic Access
Profile (GAP).
– Frequency band: ISM band 2.4 GHz
– Maximum RF power transmitted: 1 mW
– Signal range: approx. 10 m. The signal
strength depends on the ambient conditions
and the mobile device. The signal range can
vary greatly depending on local conditions and
the receiver used. The range may be percepti‐
bly reduced inside enclosed rooms and
through metal barriers (such as walls, shelves
or cases).
– Mobile terminal operating system require‐
ments: See info.myimow.stihl.com
Radio network (WLAN)
– Network standard: IEEE 802.11b/g/n
– Frequency band: 2.4 GHz
– Maximum RF power transmitted: 100 mW
Network data sheet
Communication with STIHL IoT platform
– Interface: radio network (Wi-Fi)
– Protocol and port: MQTT via TCP (8883)
Network configuration
– Interface: radio network (Wi-Fi)
– Protocol and port: DHCP/DHCPv6 via UDP
(68/546)
Communication with the "MY iMOW
– Interface: Bluetooth
– Protocol and port: proprietary via GATT
Time synchronization
– Interface: radio network (Wi-Fi)
– Protocol and port: NTP via TCP/UDP (123)
Resolution of domain names and addresses
– Interface: radio network (Wi-Fi)
2
Under ideal conditions (few obstacles, simple geometry and low gradients in garden, moderate
growth of lawn)
0458-011-9801-A
2
®
5.1. The mobile
®
" app
®
Low Energy
– Protocol and port: DNS via TCP/UDP (53)
OTA update, check of online status of the robotic
mower, communication with STIHL IoT platform
– Interface: radio network (Wi-Fi)
– Protocol and port: HTTP/HTTPS via TCP
(80/443)
Sensor data
Position data receiver / GNSS sensor
– Location data (length, width, height)
23.2 Blades
– Number of blades: 3
23.3 STIHL AAI battery
The battery has been installed in the robot
mower and must only be removed by a STIHL
®
authorized dealer.
– Battery technology: lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
23.4 Docking station and power sup‐
ply
Docking station
– Protection class: III
– Degree of protection: IPX5
– Weight: 4.0 kg
– Perimeter wire and guide wire
– Voltage: 42 V DC
– Frequency range: 1.4 kHZ to 20 kHz
Power supply
– Market-dependent versions:
– DM160E-420A
– DM160E-420AS
– DM160K-420A
– DM160S-420A
– DM210E-420A
– DM210E-420AS
– DM210K-420A
– DM210S-420A
– Weight:
– Version 160 W: 1.6 kg
– Version 210 W: 2.0 kg
– Rated voltage: See rating plate
– Frequency: see rating plate
– Rated power: see rating plate
– Charging current: See rating plate
– Protection class: II
