D) must always be made before
PROG RAM
selection.
(4) Depress desired
PROGRAM
button
(I —8).
This
stores
the
currently
sounding program into the designated
memory
location,
the WRITE
LED
will cease flashing, indicating
comple-
tion of the Write operation.
(5) set WRITE ENABLE SWITCH TO
"Disable"
position to prevent acciden-
tal memory alteration.
3. To Recall a Stored Program:
Depress the desired BANK and PRO-
GRAM
buttons.
This cancels the Manual
mode
(if
selected).
Note:
it
is not
always necessary to depress two buttons
to change programs. If the new program
is located
in the same bank
as the current
one, simply depress the new PROGRAM
button. If going from program B5 to D5,
just press the BANK D button.
Editing
The Polysix also allows the user to alter
any program either temporarily
or perma-
nently
via a powerful
and easy to use
EDIT system. The user may.
•Make any number of temporary
changes
to any program parameters or settings
previously
stores in memory,
without
changing the memory itself.
•Cancel all changes and return to the
stored program
settings.
•Make
permanent
alterations
to programs
stored in memory.
•Move
programs
from
one memory
Ioca-
tion
to another.
•Modify
a program and move the altered
version to a new location
in memory.
The
Polysix's
Programmer
is auto-
matically
in
EDIT
mode
whenever
program
is selected.
The
initial
front
panel
settings
of the
programmed
con-
trols
and
switches
have
no effect
on the
sounds produced,
which are determined
only by the values stored in memory.
However,
changes made to front
controls
and switches
after you
program will have an effect on the sounds
produced. The Edit system incorporates a
two
stage modification
system which
allows both small "incremental"
and largealterations of programvalues.
4. To
Change a Programmed
Setting:
Simply move the control in the desired
direction.
The Programmer will recognize
the change and will make a corresponding
change
to the actual
value of that
ticular synthesizer function.
This is called
Incremental Editing.
For example, if the filter Cutoff
quency (Fc) was programmed at ' '4", and
the control
was at "6"
at the time
program was selected, moving the control
to
"7"
causes
the
effective
Fc value
become "5".
If the physical endpoint
of the control
is reached, turning the control
the
opposite
direction
will
Programmer to revert that control to its
absolute setting. The control may now be
adjusted
over
its full
range, with
physical setting corresponding
the actual value of that synthesizer func-
tion. This is called Absolute
Editing.
Thus, you may make as many changes
as you like to as many controls
like,
even to the
point
Of making
program totally different from its original
state.
5. To Change a Programmed Switch Set-
ting:
a
Simply
move the switch to the desired
position.
Moving
any
switch
Programmer
to change that
switch
into
its absolute
state: the stored switch
setting is disregarded. (Note that it is
possible to move a switch with
parent change in sound occurring. This is
panel
select a
because that
switch
was moved
same position
as was stored in memory.
Moving the switch again will cause the
sound to change accordingly.)
changes
6. To Make Temporary Changes to Pro-
grams:
Control
Move controls
and switches as desired.
Each change will
be reflected in the
sound heard. You can adjust and readjust
control settings in an unlimited manner in
this manner.
par-
7. To Cancel Temporary
Simply depress the lighted PROGRAM
button. All temporary changes are erased,
Fre-
restoring the program to
sound.
the
8. To Make Changes Permanent:
To
make
changes permanent,
to
must
execute
a Write
quence (seeabovefor more details):
(1) set WRITE ENABLE to its "Enable"
slightly in
position.
(2) Depress WRITE LED switch. LED
cause the
will
flash.
(3) Depress the lighted PROGRAM but-
ton.
The
altered
the
permanently stored in the original
exactly to
location, erasing the original program.
(4) set the WRITE ENABLE switch to its
"Disable"
position.
9. To Move a Program from one location
as you
to another:
a
(I) Select the desired program in its
current location using the BANK and
PROGRAM
buttons.
(2) set WRITE ENABLE to the "Enable"
position.
(3) Depress the WRITE button. The LED
causes the
back
indicator
will
flash.
(4) Depress first
the BANK
then
the PROGRAM
ing the new program Location de-
no ap-
sired. This moves the entire program,
unaltered,
into the
program
previously
location is erased. If you want to save
that program, you must first move it
to an unused
NOTE:
The program you moved now
exists in two locations:
and the new location.
something else into the original Ioca-
tion to erase the old program.
(5) set
WRITE
able" position.
Changes:
10. To Move an Altered
new
location:
its original
(I ) Select the desired program using the
BANK
and PROGRAM
(2) Make all desired cnanges to the pro-
you
gram, using the front panel controls
into
memory
se-
and switches.
(3) When the program is altered as de-
sired, set WRITE ENABLE to the
"Enable"
position.
(4) Depress the WRITE button (LED wili
flash ).
(5) Depress the BANK and PROGRAM
program
is now
buttons
for
(BANK
button
first). This moves the altered program
to the new location.
The program previously stored at that
location is erased. If you want to keep
that program, you must first move it
to and unused location.
version of the program you altered is
still in its original location.
(6) set WRITE ENABLE to the 'iDis-
able" position.
button
and
button
indicat-
into the new location.
The
stored
in that
location.
The original
You must write
ENABLE
to the "Dis-
Program to a
buttons.
the new location
desired
must
be depressed
The original
