26.1.1 Scope of delivery
The following components are included in the scope of delivery of the M2Grip5/M2Grip5 SE:

M2Grip5/M2Grip5 SE accessories

Brief overview
The scope of delivery described above may vary and depends on the corresponding PO.
Please check the package contents immediately after receipt to ensure they are complete and undamaged.
If a shipment is incomplete or damaged, please report this immediately to the responsible office at your
company.
26.1.2 Attaching M2Grip5/M2Grip5 SE to the M2Smart
To attach the M2Grip5/M2Grip5 SE to the M2Smart
section 18.1.7).
After removing the retaining strap, the M2Grip5/M2Grip5 SE can be attached to the M2Smart
To do this, guide the nose of the M2Grip5/M2Grip5 SE to the upper retaining strap attachment and hook it in
there. Then slide the side sections of the M2Grip5/M2Grip5 SE onto the device.
Fig. 85: Attaching M2Grip5/M2Grip5 SE to M2Smart
The scanner button is now mechanically contacted and can be triggered by the scanner button in the handle.
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
®
SE
®
SE, the first step is to remove the retaining strap (see
®
SE
®
SE.
