25.6.1.1 Scope of Delivery
The following components are included in the scope of delivery of the M2Key16 Logistics:

M2Key16 Logistics plug-in module

Brief overview
The scope of delivery described above can vary and depends on the corresponding PO.
Please check the package content directly after receipt to ensure that it is complete and undamaged. If a
shipment is incomplete or damaged, please report this immediately to the responsible office at your
company.
25.6.1.2 Warning and Safety Notices
The maximum permissible ambient temperatures for the modules
are listed below.
Operating temperature:
Storage temperature:
CAUTION
Do not bring the device into contact with liquids and do not empty
any liquids onto the device.
CAUTION
25.6.1.3 Handling
After the M2Key16 Logistics module has been plugged into the main device on the lower plug-slide
mechanism, it can be used for keyboard inputs.
The default configuration is described below:
The second keyboard level (orange marked F-keys) is activated by pressing the Fn key and then the desired
F-key within 3 seconds. The activation of the second keyboard level is indicated by the LED on the Fn key,
which lights up red.
After pressing the F-key, the first keyboard level is activate again. If no F-key is pressed, the function of the
Fn key goes out automatically after 3 seconds.
The third keyboard level (green marked keys) is activated by pressing the Fn key (from level 1 press twice,
from level 2 press once) and then pressing the desired letter key within 3 seconds. The activation of the third
keyboard level is indicated by the LED on the Fn key, which lights up green.
The desired letter can be selected by repeatedly pressing the corresponding key, as in the familiar T9
keyboard. The selection is shown on the display.
The described behavior can be configured in wide parts, especially characters can be replaced. Details can
be found in the documentation
Android_de_en".
It is not possible to charge the M2Smart
plugged in.
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
-20 °C to 50 °C/-4 °F to 122 °F
-20 °C to 60 °C/-4 °F to 140 °F
„Tastaturkonfiguration-unter-Android_Keyboard-Configuration-under-
®
SE in the docking station when the M2Key16 Logistics keyboard is
