ACD GRUPPE M2Smart SE Set Kurzübersicht Seite 71

Type
Number of keys
Layout
1st keyboard level
Layout
2nd keyboard level
Layout
3rd keyboard level
25.6.1.4 Status LEDs
The status LEDs of the module will be described below.
Fn-LED flashes red:
Fn-LED lit red:
Fn-LED lit green:
25.6.1.5 Technical data of the M2Key16 Logistics
The table below includes the technical data for the M2Key16 Logistics plug-in module.
Housing
Operating
temperature
Storage temperature
Rel. humidity
Device dimensions
Weight
Keyboard/Keys
LED
Interfaces
25.6.1.6 EU declaration of conformity M2Key16 Logistics
ACD Elektronik GmbH hereby declares that the M2Key16 Logistics complies with the
directive 2014/30/EU. The complete text of the EU Declaration of Conformity is
available in the customer portal at the following internet address:
https://www.acd-gruppe.de/en/downloads/
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
Hard shell keyboard
16 keys,
10 function keys,
3 keyboard levels
0 to 9, Enter, S, C, Fn, ↑, ↓
Fn, F1 – F10,„ , ", Enter, S, ↑, ↓
Blank, a to z, „ . ", a -> A, Enter, S, ↑, ↓
The Fn LED flashes red for a short time and then green when the module is
plugged in.
The Fn LED lights up red when the Fn key is pressed once. It goes out when
another key entry is made. If no key entry is made, the Fn LED goes out after
3 seconds.
The Fn LED lights up green when the Fn key is pressed (press twice from
level 1, press once from level 2). It only goes out again after the Fn key is
pressed again or after 3 seconds.
After a keyboard entry, the third keyboard level (Fn LED lights up green)
remains active until the Fn key is pressed again.
ABS
-20 °C to 50 °C/-4 °F to 122 °F
Condensation of the device must be avoided.
-20 °C to 60 °C/-4 °F to 140 °F
5 % - 90 % non-condensing
102 x 82 x 28 mm (L x W x H)
125 g
16 keys
Bicolor LED (red/green) on the Fn key
Plug for connection to the main device
Tastatur
Technical Data
71 / 88
