25.6.4.5 Technical Data M2Longrange
The table below includes the technical data for the M2Longrange plug-in module.
Housing
Protection class
Operating
temperature
Storage temperature
Rel. Humidity
Device dimensions
Weight
Interfaces
Scanner
Reading range
Barcode Types
25.6.4.6 EU declaration of conformity M2Longrange
®
25.6.5 ePop-Loq Adapter
®
The ePop-Loq Adapter module is described below. This is an adapter module that is slid onto the side of
®
the M2Smart SE via the upper and lower plug-in sliding mechanism and is connected to a UHF RFID reader
(e.g. model 2128P) from TSL via the lower circularly arranged contacts of the ePop-Loq
®
Adapter – Front view
Fig. 78: ePop-Loq
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
ABS/PC
IP54
-20 °C to 50 °C/-4 °F to 122 °F
Condensation of the device must be avoided.
-20 °C to 60 °C/-4 °F to 140 °F
5 % - 90 % non-condensing
45 x 85 x 34 mm (L x W x H)
92.6 g
Plug for connection to the main device
2D longrange Imager SE4850
Up to approx. 17.78 m
1D barcodes
2D barcodes
ACD Elektronik GmbH hereby declares that the M2Longrange complies with the
directive 2014/30/EU. The complete text of the EU Declaration of Conformity is
available in the customer portal at the following internet address:
https://www.acd-gruppe.de/en/downloads/
Technical Data
®
Adapter – Rear view
Fig. 79: ePop-Loq
The UHF RFID reader is connected via these contacts.
®
adapter.
