ACD GRUPPE M2Smart SE Set Kurzübersicht Seite 75

The M2UHF-RFID Midrange attachable module can become very
hot during extended operation. To protect persons and the
module, the maximum time of a scan is limited to two minutes.
CAUTION
25.6.3.3 Handling
After the M2UHF-RFID Midrange attachable module has been plugged into the main device on the upper
plug-slide mechanism, it can be used for reading UHF-RFID tags.
To do this, start a software application to initialize the module. Then the read process can be carried out with
the software application.
25.6.3.4 Technical Data M2UHF-RFID Midrange
The table below includes the technical data for the M2UHF-RFID Midrange plug-in module.
Housing
Protection class
Operating
temperature
Storage temperature
Rel. humidity
Device dimensions
Weight
Interfaces
Frequency range EU
Frequency range
USA and Canada
Frequency range
China
Read range
Antenna type
RFID protocols
Output power
Radiated power
25.6.3.5 EU declaration of conformity M2UHF-RFID Midrange
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
ABS/PC
IP65
-20 °C to 50 °C/-4 °F to 122 °F
Condensation of the device must be avoided.
-20 °C to 60 °C/-4 °F to 140 °F
5 % - 90 % non-condensing
52 x 85 x 27 mm (L x W x H)
58 g
Plug for connection to the main device
865.7 MHz to 867.5 MHz
902.75 MHz to 927.25 MHz
920.625 MHz to 924.375 MHz
Up to 6 meters
Integrated Linear Polarized
EPCglobal UHF Class 1 Gen 2
ISO 18000-63 (formerly 18000-6C)
DRM (Dense Reader Mode) support
10 dBm until 27 dBm (EU and China)
10 dBm until 26.5 dBm (USA )
9 dBm until 26 dBm (EIRP)
7 dBm until 24 dBm (ERP)
ACD Elektronik GmbH hereby declares that the M2UHF-RFID Midrange complies
with the directive 2014/30/EU. The complete text of the EU Declaration of Conformity
is available in the customer portal at the following internet address:
https://www.acd-gruppe.de/en/downloads/
Technical Data
75 / 88
