20 Technical Data
20.1 Mobile Handheld Computer M2Smart
The table below includes the technical data for the M2Smart
Housing
Protection class
Operating temperature
Storage temperature
Charging temperature
Rel. humidity
Device dimensions
Weight
Power supply
Display
Touchscreen
Keyboard/Keys
Barcode scanner
(optional)
Camera
(optional)
RFID/NFC
(optional)
Processor
Memory
Operating system
Interfaces
Optional
On request
4 Registered trademark – Android
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
ABS/PC
IP54/IP65
-20 °C to 50°C/-4 °F to 122 °F
Use up to -20 °C/-4 °F in cold store or outdoors is permissible. The device
should be in operation for at least 20 minutes in advance. Condensation of
the device must be avoided.
-20 °C to 60 °C/4 °F to 140 °F
5 °C to 35 °C/41 °F to 95 °F
5 % - 90 % non-condensing
174 x 82 x 28 mm (L x W x H)
390 g
Quick-change rechargeable battery, lithium-ion with 22.8 Wh
(6.000 mAh/3.8 V)
4.8" TFT color display with LED backlight, 1280 x 720 pixels, 280 cd/m
3 status LEDs /
5" TFT color display with LED backlight, 1280 x 720 pixels, 400 cd/m
3 status LEDs
4.8" Capacitive, surface hardness to MOHS category 5-6 /
5" Capacitive, surface hardness 7H
Side on-off keys, two side scanner keys
2D shortrange Imager (SE4770) or 2D midrange Imager (SE4750MR)
integrated into housing (side scanner buttons);
Opportunity to scan DotCodes as option
5 MP auto-focus camera with illumination
Reader/Writer mode, Peer to Peer mode, Card emulation
ISO14443A/B, ISO15693, MIFARE/DESFire, Sony FeliCa
NXP i.MX8M Mini,
4x Cortex A53 (4x 1.8 GHz) and 1x Cortex M4 (1x 400 MHz)
16 GB Flash, 2 GB RAM, more memory optionally available
TM 4
Android 11
WLAN to IEEE802.11a/b/g/n/ac/d/h/e/i/r/k/w/v (2.4 GHz/5 GHz)
and BT-compatible short-range radio,
integrated loudspeaker
M2Key16 Logistics,
M2Longrange (SE4850),
M2UHF-RFID Shortrange,
M2UHF-RFID Midrange,
®
ePop-Loq Adapter
®
SOTI MobiControl
Additional customer-specific modules
TM
- Android is a trademark of Google LLC
®
