19 Expansion Variants of the Mobile Handheld Computer
19.1 2D Imager
There are 2D Imager - opportunity to scan DotCodes as option - available for the Mobile Handheld
Computer. The Imager is on top of the housing under the disk of the device. ACD Elektronik GmbH has
developed a scanner driver/scanner service to activate the scan module. The program and detailed
documentation and the development files are available from ACD Elektronik GmbH.
The table below contains the typical read distances of the 2D shortrange Imager SE4770 with laser aiming:
Barcode size
Code 39:
Code 128:
DataMatrix:
* Not specified, as the minimum/maximum distances depend greatly on the width of the barcode and
scanning angle.
The table below contains the typical read distances of the 2D midrange Imager SE4750MR with laser
aiming:
Barcode size
Code 39:
Code 128:
DataMatrix:
PDF417
19.2 Camera
There is a 5 MP auto-focus camera with flash/lighting on the rear side of the Mobile Handheld Computer.
19.3 WLAN/BT-compatible short-range radio
Optionally integrated into the Mobile Handheld Computer is WLAN according to IEEE 802.11ac/a/b/g/n incl.
802.11d, 802.11h, 802.11e, 802.11i, 802.11r, 802.11k, 802.11w, 802.11v and BT-compatible short-range
radio according to BT standard V5.0
3
WLAN security : WEP, WPA, IEEE802.11i (Personal and Enterprise), WPA2, AES, TKIP,
WPA2-PSK, 802.1x: Authentifizierung, 802.1x EAP, TLS, TTLS, PEAP, SIM, AKA, AKA-PRIME, PMK
Caching
3
Standard encryptions are ACD-validated
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en
Min. distance
3,0 mil Approx. 8 cm
4,0 mil *
5,0 mil *
20 mil Approx. 5 cm
5 mil Approx. 6 cm
10 mil Approx. 6 cm
Min. distance
20 mil Approx. 5,3 cm
100 mil Approx. 27,9 cm
5 mil Approx. 18,8 cm
15 mil Approx. 10,2cm
7,5 mil Approx. 21,1 cm
10 mil Approx. 17,8 cm
160 mil Approx. 29,2 cm
5 mil Approx. 20,6 cm
Max. distance
Approx. 14 cm
*
*
Approx. 91 cm
Approx. 24 cm
Approx. 27 cm
Max. distance
Approx. 137,2 cm
Approx. 436,9 cm
Approx. 40,6 cm
Approx. 101,7 cm
Approx. 32,5 cm
Approx. 43,2 cm
Approx. 350,5 cm
Approx. 33,3 cm
