ACD GRUPPE M2Smart SE Set Kurzübersicht Seite 56

The charging and communication contacts are very sensitive! The
Mobile Handheld Computer may only be inserted in and removed
from the docking station as described above. Do not touch the
contact with your fingers or with objects such as pens,
CAUTION
screwdrivers, etc.
Do not leave the Mobile Handheld Computer incl. battery in the
docking station for an unnecessarily long time.
CAUTION
18.1.10 Inserting the replacement rechargeable battery in and removing it from the
docking station
To insert the replacement rechargeable battery in the device, tip it diagonally downward and place it in the
rechargeable battery compartment. Insert the rechargeable battery so that the contacts are aligned with the
contacts of the docking station. Press the rechargeable battery into the rechargeable battery compartment
until it snaps in audibly.
Fig. 60: Inserting replacement rechargeable battery in the docking station
To remove the replacement rechargeable battery from the docking station, first open the lock by pressing
toward the surface of the rechargeable battery. Remove the rechargeable battery upward.
Fig. 61: Removing replacement rechargeable battery in the docking station
The charging and communication contacts are very sensitive! The
replacement rechargeable battery may only be inserted in and
removed from the docking station as described above. Do not
touch the contact with your fingers or with objects such as pens,
CAUTION
screwdrivers, etc.
Do not leave the battery in the charger or docking station for an
unnecessarily long time.
CAUTION
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.19_de_en 56 / 88
