18.1.6 Rechargeable battery change
The rechargeable battery compartment is on the back of the device. To remove the rechargeable battery,
first remove the hand strap (bottom) by unhooking it. Open the rechargeable battery cover by pressing the
lock toward the surface of the rechargeable battery. The cover can be opened and the rechargeable battery
removed.
Fig. 50: Removing the rechargeable battery
To insert the rechargeable battery in the device, tip it diagonally downward and place it in the rechargeable
battery compartment. Insert the rechargeable battery so that the contacts are aligned with the contacts of the
device. Then the rechargeable battery can be folded downward so that the lock snaps in. Then the hand
strap can be hooked back in.
Fig. 51: Inserting the rechargeable battery
®
