Number Message
60093 DC link overvoltage
60102 DC link voltage too
low for operation
60132 RS-485 communica-
tion alarm
60142 Battery undervoltage
60145 Wrong polarity on
DC terminal detec-
ted
60168 Ambient tempera-
ture over allowed
range
60186 Ambient tempera-
ture under allowed
range
60192 Fan defective or
stuck
60200 DC-DC Precharge
Conditions could
not be met.
60202 DC-link could not
be charged
60700 Auxiliary supply
overvoltage
60703 Auxiliary supply
undervoltage
Alarmmeldungen DC-DC
Warnmeldungen
Number Message
10015 IP settings have
been changed
10016 Power failure of 24-
V auxiliary supply
has been detected
10017 No right for access
parameter
102
Fehlersuche
Effect Cause
No operation possi- DC link voltage too
ble. high.
No operation possi- DC link voltage too
ble. low.
No operation possi- Communication pro-
ble. blem on RS-485
bus.
No operation possi- Battery voltage too
ble. low.
Risk of damaging Wrong polarity on
hardware. battery detected.
No operation possi- Ambient tempera-
ble. ture over allowed
range.
No operation possi- Ambient tempera-
ble. ture under allowed
range.
No operation possi- Fan is defective or
ble. stuck.
No operation possi- Precharge conditi-
ble. ons could not be
met.
No operation possi- DC link could not
ble. be charged
Risk of damaging Auxiliary supply vol-
hardware. tage too high.
Unstable system. Auxiliary supply vol-
tage too low.
Effect Cause
IP settings have Change of IP set-
been changed. tings by operator.
Depending on the Power failure of 24-
severity of power V auxiliary supply.
failure, System
Control might
sustain drop or shut
down completly.
Parameter access Insufficient access
is denied. rights.
Action
Check DC link.
Check DC link pre-
charge.
Check RS-485 com-
munication.
Check battery vol-
tage.
Check battery pola-
rity.
Check the ambient
temperature.
Check the ambient
temperature.
Check fan.
Check droop-mode
settings, DC link
and battery voltage.
Check DC link and
connected compon-
ents.
Check the external
24-V auxiliary sup-
ply.
Check the external
24-V auxiliary sup-
ply.
Action
IP adress to access
System Control
needs to be
updated.
Check 24-V auxili-
ary supply.
Make sure to only
access parameter
according to your
access rights.
2024-08-01 A67-0140-00.BKde-0
Caused
by
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
Tab. 32
Caused
by
System
control
System
control
System
control
