Danfoss VLT CDS 803 Projektierungshandbuch Seite 43

Programmieren
At power-up the user is
asked to choose the
prefered laguage.
Select language
[1] English
Setup 1
Status Quick Main
Menu
1
Menu Menu
Com.
OK
On
Warn.
Alarm
Auto
Hand
Reset
On
On
Power-up screen
OK
The next screen will be
the quick guide screen.
Press OK to start Quick Guide
Press Back to skip it
Setup 1
Status Quick Main
Menu
Menu Menu
2
Com.
OK
On
Warn.
Alarm
Hand Auto
Reset
On On
Quick guide screen
if
0.0 Hz
0.0 kW
Setup 1
3
Status Quick Main
Menu
Menu
Menu
Com.
OK
On
Warn.
Alarm
Auto
Hand
Reset
On
On
Status Screen
The quick guide can always be
entered via the Quick Menu!
Abbildung 6.2 Anwendungen ohne Rückführung
MG18N203
Projektierungshandbuch
... the CDS 803 Quick Menu starts
if OK
Danfoss A/S © 12/2015 Alle Rechte vorbehalten.
Select Language
4
[0]
English
Setup 1
Select Grid Type
5
Size related
Setup 1
Select Main Menu Password
6
[0]
Setup 1
Select Compressor Selection
7
Size related
Setup 1
Select Max. reference
8
200 Hz
Setup 1
Select Reference 1 Source
9
[1] Analog in 53
Setup 1
Select Ramp 1 Ramp Up Time
10
30 s
Setup 1
Select Ramp 1 Ramp Down Time
11
30 s
Setup 1
Select Terminal 27 Digital In
12
[6]
Stop inverse
Setup 1
Select Relay 1
13
[9]
Alarm
Setup 1
Select Relay 2
14
[5] Drive Running
Setup 1
Select Terminal 53 Low Voltage
15
0.07 V
Setup 1
Select Terminal 53 High Voltage
16
10 V
Setup 1
Select Control Site
17
[0] Digital and ctrl.word
Setup 1
Select Protocol
18
FC
[0]
Setup 1
Select Address
19
1
Setup 1
6 6
41
