Fronius InterBus 2 MB Bedienungsanleitung Seite 87

SCHALTPLAN / CIRCUIT DIAGRAM - INTERBUS 2MB RUGGED LINE
(4,045,885 B)
INTERCONNECTION WELDING CURRENT
REMOTE CONTROL REMOTE CONTROL
HOSE PACK SOURCE
CFM INTERFACE 4 INTERFACE 3 INTERFACE 2 INTERFACE 1
(OUT3) (OUT2) (OUT1) (IN)
+A1 UBST1 4,070,744
EXT
+A3
+A2 IBS2M-RL 4,070,747
NT24-24A
4,070,853
RUGGED RUGGED
LINE OUT LINE IN
