Connecting the 3.
field bus coupler 4.
(continued)
4.
5.
Configuring the
Set type of diagnosis and baud rate using DIP switch on the lower right-hand edge of the
Interbus
Interbus slave IBS2M.
1
2
3
4
Attach cable to strain relief device using cable ties
Connect external power supply with the 5-pin tension spring terminal X3: 24V =
X3.1.1/0V = X3.2.1
Connect the Interbus data line
Fit strain relief device and cover
Baud rate
2M
CLK0 Off
CLK1 Off
RF0
RF1
500k Copper
Off
On
Off
Off
5
Diagnosis
FSMA Rugged Line
On On
On On
