Data transmission properties

Transmission
RS transmission technology
technology
Network topology
Ring
Medium
Screened twisted-pair cable with screen
Transmission rate
500 kBits/s - 2MBits/s (set using DIP switch)
Bus connection
9-pin D-sub plug and 9-pin D-sub socket
ID code
0x03
Process data width
96 bits (Standard configuration)
Process data format
Motorola
LWL networks
Network topology
Ring
Medium
Polymer fibre (980/1000 µm)
Between two stations
1 - 40 m
Transmission rate
500 kBits/s - 2MBits/s (set using DIP switch)
Bus connection
F-SMA
Rugged Line
Process data width
96 bits (standard configuration)
Process data format
Motorola

Safety feature

The field bus nodes are equipped with a shutdown monitor so the power source can
interrupt the process if data transmission drops out.
on within 700ms, all inputs and outputs are reset and the power source
goes into „Stop". Once data transmission has been re-established, the
following signals resume the process:
-
-
"Robot ready" signal
"Source error reset" signal
If there is no data transmissi-
