TIG pulse range
Range selection
settings
Set pulse range on power source
Pulse setting range deactivated
0.2 - 2 Hz
2 - 20 Hz
20 - 200 Hz
200 - 2000 Hz
Output signals
Seq. no.
(from power
A01 - A08
source to robot)
A09
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25 - A32
A33 - A40
A41 - A48
A49 - A56
A57 - A64
A65 - A72
A73 - A80
Signal designation
Error number
Arc stable
Limit signal (only with RCU 5000 i)
Process active
Main current signal
Torch collision protection
Power source ready
Communication ready
Reserve
Unused
High frequency active
Unused
Wire available (cold wire)
Unused
Unused
Pulse high
Power outside range
Unused
Welding voltage (real value)
High byte
Low byte
Welding current (real value)
High byte
Low byte
Arc length (real value) (AVC)
Motor current (real value) (cold wire) 0-255 (0 - 5 A)
16
E23 E22
0 0
0 0
0 1
0 1
1 0
1 0
Field
-
-
High
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
0 - 65535 (0 - 100 V)
-
-
0 - 65535 (0 - 1000 A)
-
-
0-255 (0 - 50 V)
E21
0
1
0
1
0
1
Activity
High
High
High
High
High
High
High
-
-
High
-
High
-
-
High
High
-
-
-
-
-
-
-
-
