Interbus 2 MB signal description

General

The following data apply to Interbus (4.045.885, 4.045.923, 4.045.926)
Depending on the selected mode, the AB Profinet interface can transfer numerous kinds
of input and output signals.
Power source
Mode
modes
MIG/MAG standard synergic welding
MIG/MAG pulse synergic welding
Job mode
Parameter selection internal
Standard manual welding
CC/CV
TIG welding
CMT/special process

Overview

„Interbus 2 MB signal description" is composed of the following sections:
-
-
-
-
Input and output signals for MIG/MAG standard pulse synergic and CMT
Input and output signals for TIG
Input and output signals for CC/CV
Input and output signals for standard manual
E13
0
0
0
0
1
1
1
1
11
E12 E11
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
