Structure

5 Structure
1
4
5
8
Fig. 1: Layout of unit front
1
Fig. 2: Internal layout
MAN052993 Rev 2-01.2024
2
3
12
9 10 11
3
5
6
4
Display
1
"Down" button
2
"Up" button
3
"Mode" button
4
6
"Relay 1" LED
5
7
"OK" button
6
"Relay 2" LED
7
Cable bushing for mains cable/mains power supply
8
Cable bushing for relay output
9
pH sensor connector
10
Cable bushing for control current output
11
Cable bushing for enable input
12
Cover lock
1
Cover
2
2
Fuse 2.5 A
3
Terminal board K1–K11
4
Terminal board K12–K19
5
Terminal board K20–K25
6
