Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP
Regulations
Please observe the relevant regulations for the
installation of telecommunications and elec-
trical systems and the valid, current standards
and rules of network technology!

MountIng

2.
Note: Dimensioning and installation sketches
can be found at www.behnke-online.de/
bemassung
2.1. Junction box 20-0005-BS,
20-0005B-IP and its extension boards
Note: When placing the function modules,
please take note of the direction of the alumi-
nium brushing both for aesthetic reasons and
for dampness protection and also follow the
anti-twist protection! The door intercom station
may only be mounted with a frame that matches
the system (series). Prevent condensation
from forming inside the device! Mount the door
intercom station so that no water can remain on
the front panel. When mounting in columns or
housings of other manufacturers, pay special
attention to the ventilation of the column or
housing to prevent condensation in the inter-
com station or in the column or housing (fence
post or similar).
In case you wish to install the electronics in a
remote detached location, please use an open
counter plate (to be ordered separately) for
the appropriate front frame. When installing
reverse-side mounting components, follow the
corresponding installation instructions.
www.behnke-online.de
Connect the cables to junction box 43-9251-BS
in the following order:
1. Keys (RT) ▸ connect the HPI connectors
marked with the yellow ring (T) to the termi-
nals from call button 1 to call button 8 on the
connection board of the junction box. When
connecting third-party buttons, make sure
that the buttons comply with the relevant
approval regulations. "Bell buttons" do not
usually comply with this. Use the Behnke key
connection cable 20-9303-BS for this purpose.
Buttons must be potential-free.
In the web frontend of the SIP station, these
are designated as direct call buttons
(button 1, button 2, etc.). When operating as
an analogue intercom station on the a/b port,
refer to the configuration steps table starting
on page 78.
When connecting more than 8 call buttons,
it is always mandatory to use appropriate
extension boards. In this case, plug the call
buttons from button 1 to XX onto the extension
boards. See also 3.2. Connection diagram
25 call buttons to 75 call buttons remotely
detached. Call button configuration is perfor-
med in the configuration steps, Key 1, Key 2 to
XX.
2. Loudspeaker (LP) ▸ connect the HPI connector
marked with the blue ring to the loudspeaker
connector (LS) on the connection board in the
junction box.
3. Microphone (Mic) ▸ connect the HPI connector
marked with the white ring to the microphone
connector (Mik) on the connection board in
the junction box.
GB
Mounting
59
