Commissioning and Configuration
Status LED
The status LED is located on the connection
board at the bottom left, below the configura-
tion key (see also page 71 of this manual).
Depending on the operating mode and the state
of the device, it lights up or flashes in certain
colors.
Start phase
Restart
Analogue phone
Analogue phone without network
SIP phone: all registered configured
SIP accounts
SIP phone: configured SIP accounts
only partially registered
SIP phone: no SIP account registered
SIP phone for SIP direct calls
SIP phone for SIP direct calls without
Network
Intercom station mode
Intercom station mode without network
Hybrid mode
Hybrid mode: not all configured
SIP accounts are registered
Sabotage detected / safety shutdown
activated
temporary shutdown due to
high temperature
Firmware update
Hardware error, see section
Problems with system startup in the
appendix.
76
Select configuration (operating mode) of the
2
intercom station
For intercom stations in the delivery state, the
basic setting of the intercom station is made by
means of the configuration key. Further queries
such as the IP address can also be performed
later with this configuration key. See the
information on the configuration key (in point
5. Configuration key for an already configured
device, see page 71.
Configuration key
The configuration key is located on the connec-
tion board at the bottom left above the
earth terminal. (see also page 71 of this
manual)
Configuration of a hybrid intercom station in
delivery state as a/b intercom station
Wait for the hybrid intercom station to start.
LED should flash in red, press the configuration
key 1 once, you will be prompted to select the
language first.
German: Press 2 times
French: Press 3 times
English: Press 4 times
Then select the desired operating mode of your
intercom station.
Observe the announcement for this.
Analogue phone: press 2 times
SIP phone: press 3 times
Intercom station mode: Press 4 times, this func-
tion is only possible with a Behnke in-house
remote station (latest generation) and network
integration.
